Small and smart, the SyncEV Compact is a discrete charging solution ideal for EV owners with limited outdoor space. Packing a powerful 7.4kW punch, this untethered charger has a Type 2 socket for flexible charging.
£789.00
In collaboration with Novuna, we offer the flexibility to cover the cost of your electric car charger and installation through 10 interest-free payments. With over 40 years of experience, Novuna stands as one of the most reputable financial service providers in the UK.
We provide a warranty of 3+ years on all our EV charging products. Our warranty terms are transparent, ensuring there are no hidden costs or unexpected surprises.
We take pride in being a fully accredited installer of electric vehicle charge points and renewable energy systems by the Office of Zero Emission Vehicles (OZEV).
EVCP-7KW-S-1PH:32A BLACK
Socket – Type 2
Wi-Fi, RFID
187 (H) X 122 (W) X 90 (D) MM
7.4KW 32A MODE 3
CONFIGURABLE, 6 – 32A
220-240V, 50-60Hz, SINGLE PHASE
RAL 9005 MATT (BLACK) BODY
YES, IN-BUILT EARTH DISCONNECTION
NOT REQUIRED
YES, 6mA DC, 30mA TYPE-A, IN-BUILT
OVER CURRENT AND FAULT PROTECTION
CLASS 1, HOUSING CLASS 2
YES, OPTIONAL ACCESSORY
40A MCB OR 30mA TYPE-A RCD (Dependent on cable type &/or route)
FIRST FIX PLUG CONNECTOR
RGB LED HALO RING
BLUE – STANDBY, GREEN – CHARGING, YELLOW – NO NETWORK, RED – ERROR
UV STABILISED POLYCARBONATE
4 point with horizontal and vertical adjustment, supplied fixing hole template
IP55
IK08
AI ESP32-S SOC
RJ45
2.4Ghz 802.11 b/g/n/e/i
BT4.2
OCPP 1.6J
SYNC EV
-25 TO +40°C
OVER-THE-AIR
3 YEARS
IEC61851-1 EDITION 3.0 2017-02
Designed and developed by KatSquare
